Compared to DIN 580 carbon steel eye bolts, Grade 80 lifting eyes offer a higher capacity for equivalent thread.
Only vertical lifting is recommended. We recommend the use of swivel rings in case of angle.
The minimum tapping depth is the length of the rod plus half of its diameter.
Machinery directive2006/42/CE
- Material: Alloy, forged, tempered and tempered steel
- Marking: CE-marked
- Finish: red epoxy coating
- Safety factor: 5:1
